Yuyao Huangong automation instruments factory
$27≥5Piece/Pieces
| Вид оплаты: | T/T |
| Количество минимального заказа: | 5 Piece/Pieces |
| транспорт: | Ocean,Land,Air,Express |
| Порт: | ningbo |
Оттенок:
Модель: PB82
IModel NO.: PB8200
Measuring Medium: Steam, Gas, Liquid
Accuracy Grade: 0.2%F·S or 0.5%F·S
Pressure Range: -0.1~60MPa
IP Rating: Ip65
сертификация: CE.ISO
Ambient Temp: -20~85ºC
Output: 4~20mADC
Power Supply: 12~36VDC
Response Time: ≤10ms
Transport Package: Carton Packing
Спецификация: ПКС
Trademark: HUANGONG
Origin: China
Производительность: 120000 Pieces / Year
Настройка: Доступный
Тип: Дистанционный датчик давления
Тип структуры: Датчик уровня жидкости из диффузного кремния
Стоимость доставки: Свяжитесь с поставщиком по вопросам перевозки и примерного времени доставки.
| Продажа единиц жилья | : | Piece/Pieces |
| Тип упаковки | : | Картонная упаковка |
The file is encrypted. Please fill in the following information to continue accessing it
| Accuracy | 0.2%F·S or 0.5%F·S |
| Linearity | -0.1-60Mpa Optional, the minimum range is 0-10kpa |
| measurement range | 0.5%F·S |
| Temperature drift | ＜±0.75%F·S (0~50℃) |
| Long-term stability | ≤02.5F.S/ year |
| Esponse time | ≤10mS |
| Power supply | 12~36VDC |
| Qutput | 4~20mA、1~5V、0~5V、0~10V |
| Load Resistance | 0-60Ω (for 24VDC, 4-20mA two-wire system) |
| proof pressure | 1.5 times the maximum rated pressure |
| Output | 4…20mADC |
| Compensated Temperature | -20-85℃ (up to 300℃ or more with buffered heat pipes) |
| Storage temperature | -45~+125℃ |
| Ambient Temp | -20…85ºC |
| Pressure connection | Thread, flange, clamp can be customized |
| Mounting position | Unlimited |
| Protection | IP65 |
| Wetted parts | 304 or 316L stainless steel |
| Isolation diaphragm materia | 316L stainless steel (or Hastelloy C) |
| Power cosumption | < 0.5W(when the power supply is 24VDC |
